◆ 低騷音，高效率，省馬力?，高壓輪葉型幫浦，適用於塑膠射出成型機、壓鑄機、壓床、褶床、擠型機、工作母機、單能機等油壓機械。
◆型式號碼表示法 / MODEL NUMBER DESIGNATON
?? ?PV2R1,PV2R2,PV2R3── 25──? F──R??????
? ? ? ? ? ? ? ①? ? ? ? ? ? ? ? ? ? ? ? ? ? ②? ? ? ③? ? ④
?①?系列號碼Serial Nunber
?②吐出量 Dilivery capacity
?③裝配型式 Assemble model??????L:腳座型 Foot Type
?????????????????????????????????????????????????? ?F:法蘭型 Frange Type
?④?回轉方向 (自軸側觀之) Direction of Revolving
???????????????????????????????????????????? ?????? R:順時針方向Clock wise Direction
????????????????????????????????????????????????? ??L:反時針方向counter-clockwise direction
?◆性能表 / SPECIFICATION
|
型式
號碼
MODEL
|
吐出容積? cc/rev
DELIVERY CAPACITY
|
使用壓力kg/cm2
OPERATNG PRESS
|
回轉速度
SPEED r.p.m
|
配管尺寸PT
PORTS SIZE
|
重量
WEIIGHT (kg)
|
|||||||
|
迴轉速度SPEED( r.p.m)
|
最高
MAX
|
定格
RATED
|
最高
MAX
|
最低
MIN
|
出口
OUT
|
入口
IN
|
腳座型
FOOT
TYPE
|
法蘭型
FLANGE
TYPE
|
||||
|
1000
|
1200
|
1500
|
1800
|
|||||||||
|
PV2R1-06
|
6.1
|
7.3
|
9.2
|
11.3
|
210
|
175
|
1800
|
950
|
1”
|
1/2”
|
11.2
|
9
|
|
PV2R1-08
|
8.0
|
9.5
|
12.0
|
14.5
|
||||||||
|
PV2R1-10
|
10.1
|
12.2
|
15.4
|
18.4
|
||||||||
|
PV2R1-12
|
12.2
|
14.2
|
18.1
|
21.8
|
||||||||
|
PV2R1-14
|
13.7
|
17.0
|
21.5
|
25.6
|
||||||||
|
PV2R1-17
|
16.6
|
20.5
|
25.6
|
30.7
|
||||||||
|
PV2R1-19
|
18.6
|
23.0
|
28.8
|
34.5
|
||||||||
|
PV2R1-23
|
22.7
|
27.9
|
34.9
|
41.9
|
||||||||
|
PV2R1-25
|
25.3
|
30.0
|
37.3
|
|||||||||
|
PV2R1-31
|
31.0
|
37.3
|
46.06
|
*175
|
*160
|
|||||||
|
PV2R2-26
|
26
|
31.2
|
39
|
46.8
|
210
|
175
|
1800
|
950
|
1 1/4”
|
3/4”
|
23.3
|
19
|
|
PV2R2-33
|
? 33.0 | ? 38.5 | ? 48.1 | ? 57.7 | ||||||||
|
PV2R2-41
|
41.3
|
49.2
|
61.5
|
73.8
|
||||||||
|
PV2R2-47
|
47.2
|
57.8
|
71.3
|
86.6
|
||||||||
|
PV2R2-53
|
53.1
|
63.5
|
79.7
|
95.8
|
||||||||
|
PV2R2-59
|
59.2
|
71.0
|
88.8
|
106.9
|
||||||||
|
PV2R2-65
|
65.2
|
78.0
|
97.8
|
?*175 | ?*160 | ?1500 | ||||||
|
PV2R2-75
|
? ?75 | ?? 90 | ? 112 | ?1500 | ||||||||
|
PV2R3-76
|
76.4
|
91.5
|
114.4
|
137.2
|
210
|
175
|
1800
|
950
|
2”
|
1 1/4”
|
46.7
|
36.7
|
|
PV2R3-94
|
93.8
|
113.5
|
141.6
|
169.8
|
||||||||
|
PV2R3-116
|
115.6
|
139.2
|
174.0
|
*175
|
*160
|
?1200 | ||||||
| ? ? ?PV2R3-125 | ?125 | ? 150 | ?187.5 | ?1200 | ||||||||
